GPIO FMC
Pi HAT-compatible GPIO, dual PMOD, and M.2 wireless
A universal GPIO and connectivity hub that bridges your FPGA to the world: a Raspberry Pi HAT-compatible 40-pin header opens the entire Pi accessory ecosystem, dual PMODs handle module expansion, and an M.2 Key E slot adds standard WiFi/Bluetooth.
| GPIO | 40-pin Pi HAT compatible |
| PMOD | 2× 12-pin, adjacent |
| M.2 | Key E (WiFi/BT) |
| FMC type | VITA 57.1 LPC |
Raspberry Pi HAT compatible
40-pin GPIO connector fully compatible with the Pi HAT standard — direct electrical and mechanical use of existing Pi accessories, no adaptation needed.
Dual PMOD connectivity
Two adjacent 12-pin PMOD connectors support modules requiring dual-wide connections.
M.2 WiFi / Bluetooth
M.2 Key E (2230) connector with PCIe Gen2 x1 and USB 2.0 ULPI, designed for standard wireless modules.
Level-shifted I/O
Built-in level shifting and buffering for safe interfacing between the FPGA and external devices at various voltage levels.
Documentation
Related products
Ready to expand your GPIO?
Instant access to the Pi ecosystem, dual PMODs, and wireless connectivity.
